Description
The micro transfer bridges the gap between two conveyors or process machines.
Typical applications
-> Transfer small items off a large diameter sprocket or drum.
-> Close the gap between two machines that cannot be moved closer together.
-> Move products that would tip over or jam on a standard end transfer.
Features
-> Belt comes off without tools for easy cleaning and maintenance
-> Built with AISI 304 fully welded and bead blasted
-> IP65 motor standard, IP69K on request.
Nose bar options
-> Roller knife edge R6 to R10, (from igus). Recommended for better running and longer belt life.
-> Static knife edge R2 to R5. Belt thickness has to be added to knife edge radius.
-> Static knife edge with adjustable distance from frame. For better product handling and allows for belt tracking adjustments.
Other options
-> Belt scraper with collecting tray
Price range includes
-> Conveyor with knife edge nose bar, AISI 304 frame bead blasted.
-> Food-grade belt
-> Drum motor
-> Stainless stand with adjustable feet
-> Assembly and test run at our workshop
Not included
-> Drum motor wiring loom.
Build options
| Frame material options | Standard execution AISI 304. AISI316 on request |
|---|---|
| Belt material options | Standard PU belt. Silicone belt on request |
| Drum motor options | Standard IP65. IP69k on request |
| Food-grade motor option | regular build or drum motor with NSF H1 certified oil |
| Width options | General width ranges between 250–1000 mm |
| Length options | Minimum length ~250mm |
Characteristics
Strengths
- No-tools belt removal
- Designed for washdown environments
- Simple and reliable design
Limitations
- Reliable belt tracking for short and wide conveyors can only be achieved by plastic belt guides.
- With static knife edge belt life is much shorter than regular built conveyor types
- Light to medium duty only. Not for heavy loads
